| FRAMESET |
|
| FRAME |
Alpha Smooth Aluminum, Bosch Compact PowerTube, internal cable routing, post-mount disc, 135X5mm QR |
| FORK |
Verve alloy, threaded steel steerer, ThruSkew QR |
| WHEELS |
|
| FRONT HUB |
Formula DC-20, alloy, 6-bolt, 5x100 mm QR |
| REAR HUB |
Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm QR |
| FRONT SKEWER |
132x5mm QR, ThruSkew |
| REAR SKEWER |
155x5mm QR |
| RIM |
Bontrager Connection, double-wall, 32-hole, 20 mm width, Schrader valve |
| TIRES |
Bontrager H2 Comp, wire bead, 30tpi, 27.5x2.00" |
| MAX TIRE SIZE |
27.5x2.00" with or without fenders |
| DRIVETRAIN |
|
| SHIFTER |
Shimano U4000, 9 speed |
| CRANK |
ProWheel alloy, 170mm length |
| CHAIN RING |
ProWheel 38T narrow/wide steel, w/alloy guard |
| CASSETTE |
Shimano CUES LG300, LINKGLIDE, 11-36, 9 speed |
| CHAIN |
Shimano LG500, 9/10/11 speed |
| PEDAL |
Bontrager City pedals |
| COMPONENTS |
|
| SADDLE |
Bontrager Boulevard |
| SEATPOST |
Alloy, suspension, 31.6 mm, 300 mm length |
| HANDLEBAR |
Bar/stem w/ light mount |
| GRIPS |
Bontrager Satellite Elite, alloy lock-on |
| STEM |
Integrated stem, 35mm clamp |
| BRAKE |
Shimano MT200 hydraulic disc |
| BRAKE ROTOR |
Shimano RT26, 6-bolt, 160mm |
| BRAKE SET |
Shimano MT200 hydraulic disc |
| E-SYSTEM |
|
| BATTERY |
Bosch CompactTube 400Wh |
| CHARGER |
Bosch standard 2A, 110V, smart system |
| COMPUTER |
Bosch Purion 200 |
| MOTOR |
Bosch Active Line Plus, 50 Nm |
| ACCESSORIES |
|
| LIGHT |
Spanninga SOLO for e-bike, taillight - Herrmans H-Black MR5-E, 140 Lumen, 40 Lux, LED, headlight |
| KICKSTAND |
Alloy, rear-mount kickstand |
| CARGO RACK |
MIK-compatible alloy rear rack |
| FENDER |
SKS wide, plastic |
| WEIGHT |
|
| BIKE WEIGHT |
M - 23.50 kg / 51.81 lbs |
| WEIGHT LIMIT |
This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg). |
