FRAMESET |
|
FRAME |
Alpha Smooth Aluminum, Bosch Compact PowerTube, internal cable routing, post-mount disc, 135X5mm QR |
FORK |
Verve alloy, threaded steel steerer, ThruSkew QR |
WHEELS |
|
FRONT HUB |
Formula DC-20, alloy, 6-bolt, 5x100 mm QR |
REAR HUB |
Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm QR |
FRONT SKEWER |
132x5mm QR, ThruSkew |
REAR SKEWER |
155x5mm QR |
RIM |
Bontrager Connection, double-wall, 32-hole, 20 mm width, Schrader valve |
TIRES |
Bontrager H2 Comp, wire bead, 30tpi, 27.5x2.00" |
MAX TIRE SIZE |
27.5x2.00" with or without fenders |
DRIVETRAIN |
|
SHIFTER |
Shimano U4000, 9 speed |
CRANK |
ProWheel alloy, 170mm length |
CHAIN RING |
ProWheel 38T narrow/wide steel, w/alloy guard |
CASSETTE |
Shimano CUES LG300, LINKGLIDE, 11-36, 9 speed |
CHAIN |
Shimano LG500, 9/10/11 speed |
PEDAL |
Bontrager City pedals |
COMPONENTS |
|
SADDLE |
Bontrager Boulevard |
SEATPOST |
Alloy, suspension, 31.6 mm, 300 mm length |
HANDLEBAR |
Bar/stem w/ light mount |
GRIPS |
Bontrager Satellite Elite, alloy lock-on |
STEM |
Integrated stem, 35mm clamp |
BRAKE |
Shimano MT200 hydraulic disc |
BRAKE ROTOR |
Shimano RT26, 6-bolt, 160mm |
BRAKE SET |
Shimano MT200 hydraulic disc |
E-SYSTEM |
|
BATTERY |
Bosch CompactTube 400Wh |
CHARGER |
Bosch standard 2A, 110V, smart system |
COMPUTER |
Bosch Purion 200 |
MOTOR |
Bosch Active Line Plus, 50 Nm |
ACCESSORIES |
|
LIGHT |
Spanninga SOLO for e-bike, taillight - Herrmans H-Black MR5-E, 140 Lumen, 40 Lux, LED, headlight |
KICKSTAND |
Alloy, rear-mount kickstand |
CARGO RACK |
MIK-compatible alloy rear rack |
FENDER |
SKS wide, plastic |
WEIGHT |
|
BIKE WEIGHT |
M - 23.50 kg / 51.81 lbs |
WEIGHT LIMIT |
This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg). |
