FRAMESET |
|
FRAME |
Alpha Platinum Aluminium, internal storage, tapered head tube, Knock Block 2.0, internal guided routing, downtube guard, magnesium rocker link, Mino Link, ABP, Boost148, 120 mm travel |
FORK |
RockShox 35 Gold RL, DebonAir spring, Motion Control damper, lockout, tapered steerer, 44 mm offset, Boost110, 15 mm Maxle Stealth, 120 mm travel |
SHOCK |
Fox Performance Float DPS, 3-position damper, 185x50mm |
WHEELS |
|
FRONT WHEEL |
Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15mm thru axle |
REAR WHEEL |
Bontrager Line Comp 30, Tubeless Ready, Rapid Drive 108, 6-bolt, Boost148, 12mm thru axle |
REAR SKEWER |
Bontrager Switch thru axle, removable lever |
RIM STRIP |
Bontrager TLR |
TIRES |
Bontrager XR4 Team Issue, Tubeless Ready, Inner Strength sidewalls, aramid bead, 120tpi, 29x2.40" |
MAX TIRE SIZE |
Frame: 29x2.5" Fork: see manufacturer |
DRIVETRAIN |
|
SHIFTER |
Shimano SLX M7100, 12 speed |
CRANKSET |
Shimano Deore M6120, 30T ring, 55 mm chainline, 170 mm length |
BOTTOM BRACKET |
Shimano BB-MT501 BSA |
REAR DERAILLEUR |
Shimano XT M8100, long cage |
CASSETTE |
Shimano Deore M6100, 10-51, 12 speed |
CHAIN |
Shimano Deore M6100, 12 speed |
MAX CHAINRING SIZE |
Max: 36T (oval - 34T) Min: 28T |
COMPONENTS |
|
SADDLE |
Bontrager Arvada, steel rails, 138 mm width |
SEATPOST |
TranzX JD-YSI-22PLQ, 150mm travel, internal routing, 34.9mm, 454mm length |
HANDLEBAR |
Bontrager Rhythm Comp, alloy, 31.8mm, 15mm rise, 750mm width |
GRIPS |
Bontrager XR Trail Comp, nylon lock-on |
STEM |
Bontrager Rhythm Comp, 31.8 mm, Knock Block, 0-degree, 50 mm length |
BRAKE |
Shimano hydraulic disc, MT4100 lever, MT410 calliper |
BRAKE ROTOR |
Shimano RT56, 6-bolt, 180 mm |
ROTOR SIZE |
Max brake rotor sizes: Front see fork manufacturer, rear 180mm |
HEADSET |
Knock Block 2.0 Integrated, 72-degree radius (includes infinite-radius chip), sealed cartridge bearing, 1-1/8" top, 1.5" bottom |
ACCESSORIES |
|
BAG |
Bontrager BITS Internal Frame Storage Bag |
WEIGHT |
|
BIKE WEIGHT |
M - 14.83 kg / 32.7 lbs |
WEIGHT LIMIT |
This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg). |
