FRAMESET |
|
FRAME |
Alpha Gold Aluminum, DuoTrap S compatible, internal cable routing, flat mount disc, rack & fender mounts, 135x5mm QR |
FORK |
FX Carbon, rack and fender mounts, flat mount disc, 405mm axle-to-crown, ThruSkew 5mm QR |
|
|
WHEELS |
|
HUB FRONT |
Formula DC-20, alloy, 6-bolt, 5x100 mm QR |
HUB REAR |
Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm QR |
RIM |
Bontrager Tubeless Ready Disc, 32-hole, Presta valve |
SPOKES |
14 g stainless steel, black |
TIRE |
Bontrager H2 Hard-Case Lite, wire bead, 30 tpi, 700x32c |
|
|
DRIVETRAIN |
|
SHIFTER |
Shimano Deore M4100, 10 speed |
REAR DERAILLEUR |
Shimano Deore M5120, long cage |
CRANK |
Size: S, M Prowheel alloy, 40T narrow-wide ring, 170 mm length Size: L, XL, XXL Prowheel alloy, 40T narrow-wide ring, 175 mm length |
PEDAL |
Bontrager City pedal |
CASSETTE |
Shimano Deore M4100, 11-46, 10 speed |
CHAIN |
KMC X10, 10 speed |
|
|
COMPONENTS |
|
SADDLE |
Bontrager H1 |
SEATPOST |
Bontrager alloy, 27.2 mm, 12 mm offset, 330 mm length |
HANDLEBAR |
Size: S, M Bontrager Satellite Plus IsoZone, alloy, 31.8 mm, 15 mm rise, 600 mm width Size: L, XL, XXL Bontrager Satellite Plus IsoZone, alloy, 31.8 mm, 15 mm rise, 660 mm width |
GRIPS |
Bontrager Satellite IsoZone Plus, lock-on, ergonomic |
STEM |
Size: S Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 90 mm length Size: M, L Bontrager Elite, 31.8 mm clamp, Blendr-compatible, 7-degree, 100 mm length Size: XL, XXL Bontrager Elite, 31.8 mm clamp, Blendr-compatible, 7-degree, 110 mm length |
HEADSET |
1-1/8" threadless, sealed cartridge bearings |
BRAKE ROTOR |
Shimano RT26, 6-bolt,160 mm |
BRAKE |
Shimano hydraulic disc, MT201 lever, UR300 caliper
Shimano MT201 hydraulic disc, flat-mount, 160 mm rotor
|
BRAKE PADS |
Brake Pad Shimano Resin Disc Pad B01S |
|
|
WEIGHT |
|
WEIGHT |
M - 11.38 kg / 25.09 lbs |
WEIGHT LIMIT |
This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg). |
