FRAMESET |
|
FRAME |
Alpha Gold Aluminium, DuoTrap S-compatible, internal cable routing, rack and mudguard mounts, post-mount disc, kickstand mount, 135x5 mm QR |
FORK |
SR Suntour NEX, coil spring, preload, hydraulic lockout, 100x5mm QR, 63mm travel |
|
|
WHEELS |
|
HUB FRONT |
Formula DC-20, alloy, 6-bolt, 5x100 mm QR |
HUB REAR |
Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm QR |
RIM |
Bontrager Tubeless Ready Disc, 32-hole, Presta valve |
SPOKES |
14 g stainless steel, black |
TIRE |
Bontrager GR1 Expert, Hard-Case Lite, wire bead, 60 tpi, 700x40c |
|
|
DRIVETRAIN |
|
SHIFTER |
Shimano Deore M4100, 10 speed |
|
|
REAR DERAILLEUR |
Shimano Deore M5120, long cage |
CRANK |
Size: S, M Prowheel alloy, 40T narrow-wide ring 170 mm length Size: L, XL Prowheel alloy, 40t narrow- wide ring 175 mm length |
PEDAL |
Wellgo M141, resin body, alloy cage |
CASSETTE |
Shimano Deore M4100, 11-46, 10 speed |
CHAIN |
KMC X10, 10 speed |
|
|
COMPONENTS |
|
SADDLE |
Bontrager H1 |
SEATPOST |
Bontrager alloy, 27.2 mm, 12 mm offset, 330 mm length |
HANDLEBAR |
Size: S, M Bontrager Comp Lowriser, alloy, 31.8mm, 15mm rise, 600mm width Size: L, XL Bontrager Comp Lowriser, alloy, 31.8mm, 15mm rise, 660mm width |
GRIPS |
Bontrager XR Endurance Elite, lock-on, ergonomic |
STEM |
Size: S Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 80 mm length Size: M, L Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 90 mm length Size: XL Bontrager Elite, 31.8 mm clamp, Blendr-compatible, 7-degree, 110 mm length |
HEADSET |
1-1/8" threadless, sealed cartridge bearings |
|
|
BRAKE ROTOR |
Shimano RT26, 6-bolt,160 mm |
|
|
WEIGHT |
|
WEIGHT |
M - 13.01 kg / 28.69 lbs |
WEIGHT LIMIT |
This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg). |
