FRAMESET |
|
FRAME |
800 Series OCLV Carbon, IsoSpeed, internal storage, tapered head tube, internal cable routing, 3S chain keeper, fender mounts, flat mount disc, 142x12mm thru axle |
FORK |
Domane SLR carbon, tapered carbon steerer, internal brake routing, fender mounts, flat mount disc, carbon dropouts, 12x100mm thru axle |
FRAME FIT |
Endurance |
WHEELS |
|
FRONT WHEEL |
Bontrager Aeolus Pro 37, OCLV Carbon, Tubeless Ready, 37mm rim depth, 100x12mm thru axle |
REAR WHEEL |
Bontrager Aeolus Pro 37, OCLV Carbon, Tubeless Ready, 37mm rim depth, 142x12mm thru axle |
FRONT AND REAR SKEWER |
Bontrager Switch thru axle, removable lever |
RIMS |
Bontrager Aeolus Pro 37, OCLV Carbon, Tubeless Ready |
RIM STRIP |
Bontrager Aeolus XXX rim strip |
TIRES |
Bontrager R3 Hard-Case Lite, Tubeless Ready, aramid bead, 120 tpi, 700x32c |
MAX TIRE SIZE |
38c without fenders, 35c with fenders |
DRIVETRAIN |
|
SHIFTER |
Shimano Ultegra R8170 Di2, 12 speed |
CRANKSET |
Size 56: Shimano Ultegra R8100, 50/34, 172.5mm length |
FRONT DERAILLEUR |
Shimano Ultegra R8150 Di2, braze-on, down swing |
REAR DERAILLEUR |
Shimano Ultegra R8150 Di2, 34T max cog |
CASSETTE |
Shimano Ultegra R8100, 11-34, 12 speed |
CHAIN |
Shimano Ultegra/XT M8100, 12 speed |
MAX CHAINRING SIZE |
2x: 52/36 |
COMPONENTS |
|
SADDLE |
Size 56: Bontrager Verse Short Elite, hollow stainless steel rails, 145mm width |
SEATPOST |
Size 56: Domane carbon seatpost, KVF shaping, 20mm offset, 280mm length |
HANDLEBAR |
Size 56: Bontrager Pro IsoCore VR-SF, 42cm |
GRIPS |
Ergo-shaped hand-stitched leatherette |
STEM |
Size 56: Bontrager RCS Pro, -7 degree, 100mm length |
BRAKE |
Shimano Ultegra hydraulic disc, BR-R8170 flat mount caliper, resin pad w/fin |
BRAKE ROTOR |
Shimano CL800, centerlock, 160mm |
ROTOR SIZE |
Max brake rotor sizes: 160mm front & rear |
ACCESSORIES |
|
BATTERY |
Shimano BT-DN300 |
CHARGER |
Charging cable included |
BAG |
Bontrager BITS Internal Frame Storage Bag |
WEIGHT |
|
BIKE WEIGHT |
56 - 7.89 kg / 17.41 lbs |
WEIGHT LIMIT |
This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 275 pounds (125 kg). |
