FRAMESET |
|
FRAME |
FACT 11m carbon chassis and rear-end, asymmetrical design, 29 Trail Geometry, SWAT™ Door integration, flip chip Head Tube/Bottom Bracket adjustment, threaded BB, fully enclosed internal cable routing, 12x148mm dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, 130mm of travel |
FORK |
FOX FLOAT 34 Rhythm, GRIP damper, two position Sweep adjustment, 15x110mm axle, 44mm offset, 140mm of travel |
REAR SHOCK |
FOX FLOAT DPS Performance, Rx Trail Tune, rebound and 3-position compression adjust, 190x45mm |
SEAT BINDER |
Alloy, 38.6mm |
|
|
WHEELS |
|
FRONT HUB |
Shimano MT400-B, Centerlock 28h, 15x110 Boost |
REAR HUB |
Shimano MT510-B, Centerlock 28h, 12x148 Boost, Microspline |
FRONT TIRE |
Butcher, GRID casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3" |
REAR TIRE |
Purgatory, GRID casing, GRIPTON® T7 compound, 29x2.3" |
RIMS |
Specialized 29, hookless alloy, 30mm inner width, tubeless ready |
INNER TUBES |
Standard, Presta Valve |
|
|
DRIVETRAIN |
|
SHIFT LEVERS |
Shimano SLX, M7100, 12spd |
CRANKSET |
Shimano SLX, S1:165mm, S2-S5: 170mm, S6: 175mm |
CASSETTE |
Shimano SLX, CS-M7100, 12-speed, 10-51t |
CHAIN |
Shimano SLX, M7100, 12-speed |
REAR DERAILLEUR |
Shimano SLX M7100, SGS, 12-speed |
BOTTOM BRACKET |
Shimano, BB-MT800, Threaded |
CHAINRINGS |
30T |
|
|
COCKPIT |
|
SADDLE |
Bridge Comp, Hollow Cr-mo rails, 155/143mm |
SEATPOST |
X-Fusion Manic, infinite adjustable, two-bolt head, bottom mount cable routing, remote SLR LE lever, 34.9, S1: 100mm, S2: 125mm, S3: 150mm, S4/S5: 175mm, S6: 190mm |
STEM |
Alloy Trail Stem, 35mm bar bore |
HANDLEBAR |
Specialized, 6061 alloy, 6-degree upsweep, 8-degree backsweep, 30mm rise, 780mm width |
TAPE |
Specialized Trail Grips |
FRONT BRAKE |
Shimano SLX M7120, 4-piston caliper, hydraulic disc, 200mm |
REAR BRAKE |
Shimano SLX M7120, 4-piston caliper, hydraulic disc, 180mm |
|
|
