FRAMESET |
|
FRAME |
Size: M, L, XL Alpha Gold Aluminum, smooth welds, rack & fender mounts, internal routing, kickstand mount, 135x5mm QR Alpha Gold Aluminium, rack and mudguard mounts, internal routing, kickstand mount, 135x5 mm QR |
FORK |
Size: M, L, XL Verve Steel, threaded steel steerer, IS-disc mount, 460 mm axle-to-crown, 100x5 mm QR Alloy, IS disc, rack mounts, 415mm axle-to-crown, 5x100mm QR |
FENDER/RACK MOUNTS |
Bontrager Paradigm Comp 25, Tubeless Ready, 25mm rim width, 100x12mm thru axle |
|
|
WHEELS |
|
HUB FRONT |
Formula DC-20, alloy, 6-bolt, 5x100 mm QR |
HUB REAR |
Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm QR |
SPOKES |
14 g stainless steel, black |
RIM |
Bontrager Connection, alloy, double-wall, 32-hole, Schrader valve |
TIRE |
Bontrager H5 Hard-Case Ultimate, wire bead, 60 tpi, 700x45c |
|
|
DRIVETRAIN |
|
SHIFTER |
Size: M, L, XL Shimano Alivio M4000, 9 speed Shimano Alivio M3100, 9-speed |
REAR DERAILLEUR |
Shimano Alivio T4000, long cage |
CRANK |
Prowheel alloy, 38T steel ring, 170mm length |
CASSETTE |
Shimano HG200, 11-36, 9-speed |
CHAIN RING |
38T steel, with alloy guard |
CHAIN |
KMC X9 |
PEDAL |
Bontrager Satellite City pedal |
|
|
COMPONENTS |
|
SADDLE |
Bontrager Boulevard |
SEATPOST |
Comfort suspension, 31.6mm Alloy, adjustable suspension, 27.2 mm, 300 mm length |
HANDLEBAR |
Size: M Bontrager alloy, 31.8 mm, comfort sweep, 620 mm width Size: L, XL Bontrager alloy, 31.8 mm, comfort sweep, 660 mm width |
GRIPS |
Bontrager Satellite Elite, alloy lock-on |
STEM |
Size: M, L Bontrager alloy quill, 31.8 mm clamp, adjustable rise, Blendr-compatible, 85 mm length Size: XL Bontrager alloy quill, 31.8 mm clamp, adjustable rise, Blendr-compatible, 105 mm length |
HEADSET |
VP sealed cartridge, 1-1/8'', threaded |
BRAKE |
Size: M, L, XL Shimano MT200 hydraulic disc Tektro HD-M275 hydraulic disc, 160mm rotor |
BRAKE ROTOR |
Shimano RT26, 6-bolt,160 mm |
|
|
ACCESSORIES |
|
BATTERY |
Bosch PowerPack 400 |
CHARGER |
Bosch compact 2A (100-240V) charger |
CONTROLLER |
Bosch Purion |
MOTOR |
Bosch Active, 250 watt, 40 Nm, 20mph or 32km/h |
LIGHT |
Spanninga SOLO for e-bike Herrmans H-Black MR4-E, 40Lux/120 lumen Lync front light [p14] Lync fender-mount tail light |
KICKSTAND |
KICKSTAND, MASSLOAD KICKSTAND CL-KA98 ED BLACK AL6061 |
CARGO RACK |
Alloy rear rack |
|
|
WEIGHT |
|
WEIGHT |
M - 23.36 kg / 51.5 lbs |
WEIGHT LIMIT |
This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg). |
