FRAMESET |
|
FRAME |
Alpha Platinum Aluminium, tapered head tube, internal derailleur & dropper post routing, rack mounts, 197x12 mm adjustable horizontal sliding dropouts |
FORK |
Bontrager Haru, tapered alloy steerer, OCLV Carbon lowers, 490mm axle-to-crown, 15x150mm thru axle |
MAX COMPATIBLE FORK TRAVEL |
100mm (513mm axle-to-crown) |
|
|
WHEELS |
|
FRONT HUB |
Bontrager alloy, sealed bearing, 6-bolt, 15x150mm thru axle |
REAR HUB |
Bontrager alloy, sealed bearing, 6-bolt, Rapid Drive 108, Shimano 10 freehub, 197x12mm thru axle |
TIRES |
Bontrager Gnarwhal Team Issue, Tubeless Ready, Inner Strength sidewalls, studdable, aramid bead, 120 tpi, 27.5x4.50'',Bontrager Gnarwhal Team Issue, Tubeless Ready, Inner Strength sidewalls, studdable, aramid bead, 120 tpi, 27.5x3.80'' |
MAX TIRE SIZE |
27.5x4.50" or 26x4.70" |
SKEWER |
Front: Bontrager Switch thru axle, removable lever Rear Bontrager Switch thru-axle. Removable lever |
RIM |
SUNRingle Mulefut 80 SL, 32-hole cutout |
|
|
DRIVETRAIN |
|
SHIFTERS |
Shimano Deore M4100, 10 speed |
REAR DERAILLEUR |
Shimano Deore M5120, long cage |
CRANK |
Race Face Ride, 28T steel ring, 175mm length |
CASSETTE |
Shimano Deore M4100, 11-46, 10 speed |
CHAIN |
KMC X10, 10 speed |
BRAKES |
SRAM Level Front Disc Brake Brake Rotor: Avid G2 CleanSweep, 6-bolt, 160mm |
STEM |
Size: M Bontrager Elite, 31.8mm, Blendr-compatible, 7-degree, 70mm length Size: L Bontrager Elite, 31.8mm clamp , Blendr compatible, 7 degree, 80mm length |
|
|
COMPONENTS |
|
SADDLE |
Bontrager Arvada, steel rails, 138 mm width |
SEATPOST |
Size: M TranzX JD-YSP18, 120 mm travel, internal routing, 31.6 mm, 403 mm length Size: L TranzX JD-YSP18, 130mm travel, internal routing, 31.6 mm, 425 mm length |
HANDLEBAR |
Bontrager alloy, 31.8mm, 15mm rise, 750mm width |
GRIPS |
Bontrager XR Trail Comp, nylon lock-on |
HEAD SET |
FSA IS-2, 1-1/8'' top, 1.5'' bottom |
WEIGHT |
M - 14.66 kg / 32.33 lbs (with tubes) |
|
|
